CAT CAT305.5E2

Prijs excl. BTW

Images10
CAT CAT305.5E2 Minigraafmachines < 7t
CAT CAT305.5E2 Minigraafmachines < 7t
CAT CAT305.5E2 Minigraafmachines < 7t
FavoriteFavoriet
shareDelen
Save searchZoekopdrachten bewaren
Afdrukken

INFORMATIE

Productcategorie
Minigraafmachines < 7t
Merknaam / type
CAT CAT305.5E2
Jaar
2024
Gebruiksuren
450 h
Status
Gereviseerd / Remanufactured
Land
China
Algemene score
1
2
3
4
5
Mascus ID
77BC2619

PRIJSLIJST

Kies valuta

DETAILS

Type
Diesel
Onderhoudsgeschiedenis
Ja
Aantal vorige eigenaren
1
Conditie van het onderstel
good
Totaalgewicht GVW
5.500 kg
Emissieklasse
Fase V
Rupsbreedte
400 mm
Inhoud graafbak
0,22 m3
Afmetingen (LxBxH)
576519502.54 m
Originele kleur
YELLOW
Lengte lepelsteel
960 mm
Motor
Cat C2.4 DI
Motor vermogen
34,1 kW (46,4 pk)
Motor fabrikant
JAPAN
Voorwaarden info/Garantie
good
Land van fabricage
Japan
Leveringsvoorwaarden
FOB, CIF, EXW
Certificaten
EPA, CE, ANSI, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME
Toebehoren
All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.
Accessoires
Kabelkast
Airconditioning
Aanvullende hydraulica
AdBlue
Alles bekijken
Extra informatie
The performance parameters of the Caterpillar CAT305.5E2 excavator are as follows: 1. **Overall Dimensions of the Machine** - Total transportation length: 5765mm, total transportation width: 1950mm, total transportation height: 2540mm, minimum ground clearance: 628mm, rear swing radius: 1580mm, total track length: 2440mm, track gauge: 1550mm, track shoe width: 400mm, center distance between idler wheels: 1920mm. 2. **Operating Weight** - The operating weight of the whole machine is 5400kg. 3. **Bucket Capacity** - The bucket capacity is 0.22 cubic meters. 4. **Power System** - Engine model: Cat C2.4 DI, rated power: 34.1kW, cylinder bore: 87mm, stroke: 102.4mm, displacement: 2.4L. 5. **Performance Parameters** - Swing speed: 10.5rpm. - Gradability: 50%. - Bucket digging force: 35.0kN. - Stick digging force: 27.2kN. - Maximum drawbar pull: 40.2kN. - Travel speed: 4.3/2.8km/h. - Swing torque: 13.9N·m. 6. **Hydraulic System** - Maximum main pump flow: 140L/min. The type of the main pump is a load sensing hydraulic system equipped with a variable displacement piston pump, and the working hydraulic circuit pressure is 25MPa. 7. **Oil Capacity** - Fuel tank: 78L, hydraulic oil tank: 58L, engine oil change capacity: 9.5L, coolant: 9.8L. 8. **Working Range** - Maximum digging radius: 5955mm. - Maximum digging depth: 3720mm. - Maximum digging height: 5460mm. - Maximum unloading height: 3835mm. - Maximum vertical digging depth: 2210mm. 9. **Bulldozer Blade Parameters** - Lifting or pushing depth: 365mm/480mm, width×height of the bulldozer blade: 1950mm×360mm.Alles bekijken

Shanghai FanChi Machinery trading Co., LTD

hongmei Road 200000 Minhang Shanghai 上海 China
