CAT 262 D
Prijs excl. BTW
Afdrukken
INFORMATIE
Productcategorie
Schrankladers
Merknaam / type
CAT 262 D
Jaar
2021
Gebruiksuren
1.100 h
Status
Nieuw/ongebruikt
Land
China
Algemene score
1
2
3
4
5
Mascus ID
AE7275F9
PRIJSLIJST
Kies valuta
DETAILS
Type
Diesel
Conditie van het onderstel
perfect
Aantal vorige eigenaren
0
Totaalgewicht GVW
3.700 kg
Maximale hefcapaciteit
2.000 kg
Type opbouw
Star chassis
Type cabine
Gesloten cabine
Emissieklasse
Stage IIIA / Tier IV interim
Motor
caterpillar
Inhoud graafbak
0,60 m3
Motor vermogen
56 kW (76,1 pk)
Motor fabrikant
caterpillar
Topsnelheid
30 km/h
Originele kleur
yes
Voortbeweging, wielen - rups
Wielaandrijving
Voorwaarden info/Garantie
perfect
Resterend profiel voorwielen
100
Resterend profiel achterbanden
0
Land van fabricage
Verenigde Staten
Leveringsvoorwaarden
CIF, EXW
Accessoires
Airconditioning
Aanvullende hydraulica
Machine besturingssysteem
Brandblussysteem
Kantelbare snelsluiting
AdBlue
Camera
Loadsensing
Afgeknotte driehoek
Back-up alarmsysteem
Grijper
Stuurknuppel
Extra informatie
Caterpillar CAT ® The detailed parameters of the 262D skid steer loader are as follows:
Technical parameters:
Suspension length of bumper behind rear axle: 1083.0 mm
Extension distance at maximum lifting and unloading position: 786.0 mm
Gap at maximum lifting and unloading position: 2380.0 mm
Rear inclination angle at maximum height: 84 °
The height of the bucket connecting pin at the transport position is 200.0 mm
Maximum unloading angle: 51 °
Maximum total height: 4008.0 mm
Bucket connection pin height at maximum lifting height: 3172.0 mm
Extension distance of bucket connecting pin at maximum lifting height: 393.0 mm
Departure angle: 26 °
Ground clearance: 226.0 mm
Maximum extension distance when the arm is parallel to the ground: 1293.0 mm
Steering radius from center to rear of machine: 1805.0 mm
Turning radius from center to connector: 1401.0 mm
Steering radius from center to bucket: 2181.0 mm
Height to the top of the cab: 2110.0 mm
Vehicle width (including tires): 1676.0 mm
Wheelbase: 1249.0 mm
Length of bucket when placed on the ground: 3714.0 mm
Length (excluding bucket): 2995.0 mm
Hydraulic system parameters:
Hydraulic flow rate (standard): 33.0 kW
Loader hydraulic pressure: 23000.0 kPa
Hydraulic flow rate of loader: 86.0 l/min
High flow XPS hydraulic flow rate (standard): 57.0 kW
High flow XPS maximum loader hydraulic pressure: 28000.0 kPa
High flow XPS maximum loader hydraulic flow: 121.0 l/min
Cabin parameters:
Compliant with ROPS ISO 3471:2008 and FOPS ISO 3449:2005 Level I standards
Power transmission system parameters:
Driving speed (forward or reverse, single speed): 12.5 km/h
Driving speed (forward or reverse, dual speed option): 17.7 km/h
Maintenance and refueling capacity:
Cooling system: 14.0 l
Engine crankcase: 11.0 l
Fuel tank: 94.0 liters
Hydraulic system: 52.0 l
Hydraulic oil tank: 39.0 l
Each side chain transmission box: 12.7
