Putzmeister M49-5

Prijs excl. BTW

Images35Videos1
Putzmeister M49-5 Betonpomptrucks
Putzmeister M49-5 Betonpomptrucks
FavoriteFavoriet
shareDelen
Save searchZoekopdrachten bewaren
Afdrukken

INFORMATIE

Productcategorie
Betonpomptrucks
Merknaam / type
Putzmeister M49-5
Jaar
2013
Gebruiksuren
3.000 h
Status
Hersteld / Reconditioned,Gereviseerd / Remanufactured
Land
China
Algemene score
1
2
3
4
5
Mascus ID
8A178F24

PRIJSLIJST

Kies valuta

DETAILS

Voorraad nummer
AICPT026
Aantal giekdelen
5
Datum van de laatste inspectie
2024-09-26
Totaalgewicht GVW
32.000 kg
Lengte van kraanarm
400 cm
Maximaal horizontaal bereik
3.730 cm
Maximaal verticaal bereik
4.160 cm
Movement type
Static
Voeding
Diesel
Pomp vermogen
300 kW
Afmetingen (LxBxH)
11500 x 2500 x 4200 mm
Emissieklasse
Fase V
Motor fabrikant
Mercedes Benz OM501LA.III/17
Type pomp
Zuiger
Fabrikant chassis
Mercedes Benz
Banden merk
Mercedes Benz
Land van fabricage
China
Leveringsvoorwaarden
FOB, CIF
Certificaten
EPA, CE, TÜV
Toebehoren
Boom M 42-5 Sections 5 Reach height m 41.6 Horizontal reach gross m 37.3 net m 34.5 Reach depth max. m 31.0 Unfolding height m 8.6 End hose length m 4 Folding system RZ Delivery line DN 125 Pump BSF .16 H .17 i LS Rod side Output m³/h 160 - Delivery pressure bar 85 - Strokes 1/min. 31 - Piston side Output m³/h 108 170 Delivery pressure bar 130 85 Strokes 1/min. 21 27 Delivery cylinder Ø mm 230 250 Stroke mm 2100 2100
Extra informatie
Truck-mounted concrete pump 49-5 Efficiency and flexibility on 4 axles Get ahead with 5 arms 49-5, this means a 49 m vertical reach distributed over 5 arms with a compact design in roll Z-folding system. 5 arms, this means a high degree of versatility. Optimized kinematics also ensures that there is no noticeable dead space. A placing boom in roll Z-folding system combines a compact design with a low unfolding height, optimum slip characteristics and the best use of the horizontal reach from the front edge of the truck. This means that you benefit from the advantages of the roll and of the Z-folding system in an economic way. Get closer to the action with less space requirement Set-up times can be kept as short as possible. With the TRDI support developed by Putzmeister, you save time and space, without compromising on safety. Double telescoping support legs can also be securely placed in minimal spaces between obstacles. Thanks to the optional One Side SupportAlles bekijken

Achieve Innovations

5F Building 4, No.28, (M) Fuyuan Road, Kaifu Dist 410003 Changsha Hunan 湖南 China
