Liugong CLG855N

Liugong CLG855N loader parameter configuration Basic performance Rated load (tons): 5-6 tons. Rated load (kg) is 5000. Machine working weight (kg) 16300200 Bucket capacity (m) 2.7-4.0 Unloading height-unloading angle is 45 (mm) 3100. Unloading distance-unloading angle is 45 (mm) 1100. Digging force (kN) 167 engine Engine model Weifang Steyr WD10G220E21 Rated power (kw/rpm) is 162/2200 Maximum torque (Nm) 860 Cylinder diameter × stroke (mm) 126 × 130 Working mode: Inline 6-cylinder; 4 strokes; supercharged direct injection Power System Battery voltage (V) 6-QW-120T (24V) Oil capacity Fuel tank (L) 290 Hydraulic oil tank (L) 250 gearbox Transmission planetary hydraulic shift make and model Driving speed 1st gear (km/h) 11.5/16 Driving speed second gear (km/h) 38 drive shaft Model transaxle four-wheel drive Steering system Steering angle is 36° Turning radius - bucket outside (mm) 723850 Minimum turning radius of outer wheel centerline 6205 hydraulic system Rated working pressure (bar) is 18 MPa. Boom cylinder bore × stroke (mm × mm) 2-160 × 838 Cylinder diameter × bucket stroke (mm × mm) 1-200 × 500 Working time of working device Elevator 6.5 Uninstall version 1.5 Lower empty bucket 3.5 Items 3 and 11.5 Technical Parameters Maximum traction force (kn) 1505 Material position height (mm) 4160 Distance from rear wheel axle to hinge point (mm) 2150 Overall size Total length (mm) 7860 Overall width (mm) 2741 Total height (mm) 3500 Minimum ground clearance (mm) 490 Bucket width (mm) 2984 Wheelbase (mm) 3250 Track (mm) 2200
